 PVS
meets all USA Volleyball, NCAA, NFHS and FIVB requirements for competition
equipment.
Adjusts
to all competition heights.
Clear
anodized finish for professional looking appearance.
High
maneuverability—lightweight and easy to handle.
Easy
setup—requires only one person just a few minutes.
Secure
cast-in-place 3-1/2" I.D. floor sleeves with flush cover plates
provide rigid support—for the life of the installation.
Tensioning
winch is a heavy-duty, self-locking wormgear mechanism. A heavy
2" wide, high tensile strength, nylon strap with heavy-duty
snap hook eliminates the possibility of hooks breaking and guarantees
safe connection to the net-top cable.
Easy
storage—can be hung on a wall with hooks, stored on optional
transporter or tucked away in a closet.
Heavy-duty
construction—built for years of trouble-free service and rough
use.
Accessories
|
|
|
|
|
|
|
Telescoping
Aluminum Standards—One pair
of 3-1/2" O.D. high strength tubular standards. Height adjustment,
from 6'1" to 8'4" in 1" increments. Power winch is
located on the outside of one upright.Second upright is equipped
with tiedown cables and adjustable collar.
Power Volleyball Net—32'
x 39-3/8". Official competition net. Netting is 4" square
#36 black nylon cord with vinyl-coated polyester hem double stitched
around entire perimeter of net. Top hem has a 42'6" long galvanized
aircraft cable with a nylon coating for top tensioning. Bottom of
net has a braided white nylon rope for bottom tensioning. Each side
of the net is equipped with three polypropylene tension straps with
buckles.
Rope Tensioner—A
spring loaded rope tensioner holds the bottom of the net taut.
Boundary Markers—A
pair of 2" wide white polyester reinforced vinyl strips, one
for each end of the net.
Antennae—A
pair of 3/8" dia. fiberglass rods with alternating red and
white 4" stripes.
Optional Protective Pads—Upright pads provide maximum player protection. Two, 5'8" high
pads are constructed of 1-1/2" thick, cross-linked polyethylene
foam covered with polyester reinforced vinyl fabric. Dark blue is
standard; other colors available.
 |
