ShadowBox Clarion Fixed Projection Screen

ShadowBox Clarion fixed screen delivers a sleek wall-mounted frame that delivers sharp, high-quality images for commercial and custom installs.

The ShadowBox Clarion fixed projection screen features a sleek, wall-mounted extruded aluminum frame with snap attachments, for a perfectly flat viewing surface. This taut design enhances sharpness and clarity, making it ideal for conference rooms, auditoriums, and educational spaces. The aluminum frame features a black powder coated finish for a smooth, finished look.

5-Year Warranty* Ready to purchase

Product Specs

Maximum image width up to 16' (488 cm) wide. Custom sizes available.

Designed for wall mounting. Mounting fasteners not included.

The frame includes a mounting flange that mates with wall brackets.

Viewing surface snaps securely to the back of the 1-1/2" (38 mm) extruded aluminum frame.

Aluminum frame has a black powder coat finish.

Custom curved designs are available for specialized installations. Contact Draper^® for details.

Viewing Surfaces Available:

TecVision^® XH700X Premium Contrast Grey

TecVision^® XH800X ALR

TecVision^® XH900X ALR

TecVision^® MS1000X ALR

TecVision^® CS1100X ALR

TecVision^® XH1200X Premium Contrast Grey

TecVision^® XT1000X White

TecVision^® XT1100X White

TecVision^® XT1300X White

TecVision^® XT1600X White

TecVision^® XH700X Grey NanoPerf

TecVision^® XH900X ALR NanoPerf

TecVision^® MS1000X ALR NanoPerf

TecVision^® XT1000X White NanoPerf

TecVision^® XT1100X White NanoPerf

TecVision^® XT1300X White NanoPerf

TecVision^® XT1600X White NanoPerf

TecVision^® XH1200X Grey NanoPerf

TecVision^® CS1100X ALR NanoPerf

Matt White XT1000VB

Grey XH600V

CineFlex CH1200V

CineFlex White XT700V

ClearSound NanoPerf XT1000V

Supporting Documents

Click the and icons to navigate the folders. Click the document name to download.

Installation Instructions

CSI 3-Part Specifications

Submittal

BIM Object

Care and Maintenance Instructions

Product Page

Warranty

BIM Support

Sizes, Part Numbers & Prices

View all available sizes and surfaces on one page

Surface Material: Image Format: Diagonal (Image area): Unit of measure:

Imperial (USA)

Metric

Part number:	253124
Surface material:	Matt White XT1000VB
Image Format:	16:10
Diagonal size:	94"
Image/Viewable area:	50" x 80"
Overall size:	53" x 83"
Product weight:	30 pounds
Shipping weight:	34 pounds
U.S. Retail Price:	$1592

Draper^® manufactures custom size screens to meet your specification. Virtually any size within the maximum shown for a given model is available. Please call for pricing on special sizes.
